Caption: Effective area of the Athena/X-IFU compared to one of the XRISM Resolve instruments, both being imaging spectrometers. The effective area of three dispersive spectrometers are also shown (contours in dashed lines): two currently in operation, namely XMM-Newton RGS and Chandra HETG, and Arcur proposed to NASA as a MIDEX and completing currently its Phase A concept study.

Additional comments: X-IFU offers imaging capability with a pixel size of less than 5" to be compared with the 1' pixel size of the XRISM Resolve instrument.

Reference: Data provided by Randall Smith for the Arcus effective area (26/11/2018). Smith, Randall and the Arcus Collaboration, 2018, American Astronomical Society, AAS Meeting #231, id. 237.18

Creation Date: 26/11/2018. Version #:3

Credits: X-IFU Consortium. Copyrights: © DB/X-IFU.
